Model number: TRA72054-5RNR
Product Details
Fuel Type: Electric
Needed to Complete (not included):
- Hobby knife
- Glue
- Paint and finishing tools
NOTE: Photo of completed model is for illustrative purposes only. This is a model kit that requires assembly.
More info
Here's the new Traxxas 1/16 scale Summit ! Traxxas stuffed a 1/10 scale 550 size motor in this mini monster truck. Feel unstoppable power and nearly limitless torque from the Titan 12T 550 motor. With massive suspension travel, extreme Titan power, and 4-wheel drive traction, Summit tackles impossible terrain. Traxxas engineers combined all the big Summit's go-anywhere versatility with waterproof electronics to make even your wildest adventures possible. Summit’s bright LED lights blaze a trail, making night runs more exciting than ever. The 1/16 Summit's just-right size lets you enjoy hours of off-road fun anytime, anywhere!
Features:
- TQ™ 2.4GHz transmitter
- AC wall-outlet charger
- 7.2 volt NiMH battery pack with iD®
- Patented Traxxas High-Current Connector delivers maximum voltage
- Race-winning Revo® suspension technology, perfectly optimized for 1/16 scale
- 1/10th scale Titan® 12T modified motor
- XL-2.5 Waterproof Electronic Speed Control
- LiPo and NiMH compatible with two-stage low-voltage detection
- Full LED light kit
- Digital High-Torque Waterproof Micro Steering Servo
- Waterproof, o-ring sealed receiver box
- Sealed, silicone-filled differentials—an industry first in 1/16 scale
- Torque-Control™ slipper clutch system
- Heavy-duty CV-style driveshafts
- Rubber-sealed ball bearings
- Extended-wheelbase rear suspension arms (+10 mm)
- Rocker-actuated shocks provide true progressive damping and spring rates
- Threaded-body, oil-filled shocks permit fast, precise preload adjustments and deliver smooth, consistent damping
- Integrated battery compartments with intake and exit cooling vents
- Quick-release battery doors for fast pack changes
- Scale all-terrain front and rear tires offer superior on- and off-road traction
- Pre-glued Canyon AT™ Tires with foam inserts
- Black Geode 2.2" wheels with beadlock trim
- ExoCage body with protective outer cage
Specifications:
| Length: | 12.6 inches (320 mm) | |
| Front Track: | 10.43 inches (265 mm) | |
| Rear Track: | 10.63 inches (270 mm) | |
| Weight: | 46.4 ounces (1.31 kg) | |
| Height (Overall): | 7.48 inches (190 mm) | |
| Wheelbase: | 8.43 inches (214 mm) | |
| Wheel Diameter | 2.2" (56 mm) | |
| Shock Length (Front / Rear): | 48 mm / 48 mm | |
| Front/Rear Tires (Glued): | Canyon AT | |
| Front/Rear Wheels: | Geode™ | |
| Electronic Speed Control: | Waterproof XL-2.5 ESC | |
| Motor (Electric): | Titan® 12T 550 | |
| Transmission: | Heavy-Duty Single Speed | |
| Gear Ratio (Internal): | 5.04:1, (Reversed Input: 9.72:1) | |
| Overall Drive Ratio: | 15.75:1 (stock) | |
| Differential Type: | Hardened Steel Bevel, Sealed | |
| Gear Pitch: | 48-Pitch | |
| Chassis Structure/Material: | Molded Composite Nylon Monocoque | |
| Brake Type: | Electronic | |
| Drive System: | Shaft-Driven 4WD | |
| Steering: | Bellcrank | |
| Radio System: | Traxxas TQ™ 2.4GHz (2-Channel) | |
| Included Charger: | AC Wall-Outlet Charger | |
| Included Batteries: | 6-cell NiMH with iD Connector | |
| Required Batteries: | 4 "AA" (Transmitter) (vehicle includes 6-cell NiMH & charger) |
Needed to complete:
- (4)AA batteries for the transmitter.
